Number Word Quantity Lose Into 参 number |
aisle | 16 channels of isolation / 16 channels of counting (independent) |
|---|---|---|
| Dry contact | stand by | |
| Wet joint | Support bidirectional: high level: +10V ~ +50V low level: ≤ +3V | |
| Input frequency | 3kHz Max | |
| Isolation voltage | 3KV Vdc |
|
Master Board 参 number |
operating system | FreeRTOS |
|---|---|---|
| Processor | STM32 (Cortex-M3) | |
| Processor speed | 120MHz | |
| LED indicator | Power light, communication light, channel light | |
| Watchdog | System watchdog, communication watchdog (programmable) | |
| Protective function | Overcurrent, overvoltage, overtemperature, anti-reverse | |
| Communication Interface | 2xRJ45 (daisy chain networking, support for Bypass function) | |
| Upgrade program interface | Built-in MiniUSB | |
| letter of agreement | Modbus-TCP |
|
Machine Structure And Ring 境 参 number |
shell material | ABS plastic |
|---|---|---|
| Dimensions | 98×106×47mm | |
| Rail support | DIN35mm | |
| power input | 10 to 48V (24Vdc rated) | |
| Power consumption | ~2.5W (24Vdc) | |
| Operating temperature | -20 to 70 ° C | |
| Storage temperature | -30~80°C | |
| Humidity | 10 to 90% RH (non-condensing) | |
| Weight | ~0.28Kg | |
| Certification and testing | EMC (EN61000-6-2/4), safety regulations | |
| Parameter setting software | WTDUtility |
